Durable Woven Wire Mesh for Precision Screening and Filtration
Banaraswala manufactures woven wire mesh in SS304, SS316, GI, brass and aluminium for industrial screening, filtration and separation. Available in plain, twill and Dutch weave patterns from 2 mesh to 500 mesh with custom sizes and pan-India supply.
.avif)
What is woven wire mesh?
Woven wire mesh is manufactured by interlacing metal wires on industrial looms, similar to how fabric is woven. The result is a precise, uniform grid with consistent openings that makes it ideal for filtering, sieving, and screening applications across industries.
Each wire passes alternately over and under adjacent wires. The simplest and most versatile pattern, suitable for general-purpose screening and filtration.
Each wire passes over two and under two adjacent wires, creating a diagonal pattern. Produces a tighter, more flexible mesh ideal for fine filtration.
Uses thicker warp wires and thinner, tightly packed weft wires to create an extremely dense surface. Used for high-precision filtration down to 2 microns.
Technical Specifications
We engineer precision metal products for diverse industrial applications.
Mesh count range
2 mesh (coarse) to 500 mesh (ultra-fine)
Aperture sizes
11.1 mm down to 0.002 mm (2 microns)
Wire diameter
0.025 mm to 1.6 mm
Formats
Rolls (SQM) and cut-to-size pieces (Nos)
Materials
SS304, SS316/316L, GI, Brass, Phosphor Bronze, Aluminium, Nylon, HDPE
Weave Types
Plain, Twill, Dutch (Plain Dutch and Twilled Dutch)
Roll Widths
Standard 1000 mm and 1220 mm; custom widths available
Tolerances
As per IS 460 / ASTM E2016 standards
.jpg)
Applications
Woven wire mesh is widely used for industrial filtration, particle separation, sieving, grading, machine guarding, insect screening and architectural applications. Industries served include pharmaceuticals, food processing, chemicals, mining, aggregates, water treatment, agriculture, oil & gas and manufacturing.
Why Banaraswala For Woven Wire Mesh ?
Controlled weaving, calibrated wire and in-process quality checks ensure consistent aperture accuracy and wire diameter. As an ISO-certified woven wire mesh manufacturer, we verify open area and dimensional tolerances for every batch and provide custom-cut panels, framed screens and bulk supply across India.
Frequently Asked Question
Trusted in more than 100 countries and 4 million customers.
Woven wire mesh is widely used in pharmaceuticals, food processing, chemical manufacturing, mining, water treatment, agriculture, oil and gas, and general industrial filtration and screening applications.
Yes. Fine woven mesh, especially Dutch weave variants, is suitable for high-precision filtration and can be used to separate very small particles in industrial processes.
Yes. Banaraswala manufactures woven wire mesh in SS304 and SS316/316L, along with materials such as GI, brass, phosphor bronze and aluminium, depending on the application.
Yes. Stainless steel and galvanised woven wire mesh offer good corrosion resistance, making them suitable for outdoor, humid and demanding industrial environments.
Yes. We supply woven wire mesh in standard rolls as well as cut-to-size pieces based on customer specifications and project requirements.
The right choice depends on factors such as mesh count, wire diameter, material, aperture size and operating conditions. Our team can help you identify the most suitable specification based on your application.
