Heavy-Duty Vibrating Screen Mesh for Mining, Quarrying, and Aggregate Processing
Manufactured in Spring Steel (SPS), SS304, SS316, SS310, and GI. Available with or without clamps. Custom screen sizes for all major vibrating equipment brands.
What is Vibrating Screen Mesh?
Vibrating screen mesh, also called crimped wire mesh or wire screen, is a heavy-duty woven wire product designed for use on vibrating screen equipment. The wires are pre-crimped before weaving, which locks them in position and provides superior stability under the high-impact, abrasive conditions found in screening and classification applications.
Screens manufactured with hooked or clamped edges for tensioned mounting on vibrating equipment. The clamp side is customised to fit specific machine models and frame dimensions.
Plain crimped mesh supplied in roll form (SQM). Used where the end user or OEM cuts and fabricates screens to their own specifications.
Crimped mesh supplied as pre-cut flat panels in specific dimensions. Available in both zig-zag and plain crimp patterns.
Technical Specifications
We engineer precision metal products for diverse industrial applications.
Opening Sizes
1 mm to 100 mm
Wire Diameters
1.4 mm to 12 mm
Materials
Spring Steel (SPS/HCS), SS304, SS316, SS310, SS314, GI
Crimp Patterns
Zig-Zag (Z) and Plain (P)
Formats
With Clamp (WSC), Rolls (WSS in SQM), Cut Pieces (WSN in Nos)
Clamp Options
Hook type, bolt-down, and pin-strip to fit all major vibrating screen brands
Common Screen Sizes
Custom to machine specifications. Standard panels up to 2000 x 1200 mm
Tolerances
Opening size +/- 0.5 mm, wire diameter as per IS 4454 / ASTM A227
.avif)
Applications
Used in mining, quarrying, aggregate processing, sand classification, stone crushing, cement manufacturing, fertiliser production, recycling plants, and coal screening. Key equipment brands served include Metso, Sandvik, Terex, Puzzolana, and all major Indian and international OEMs.
Why Banaraswala ?
Controlled weaving, calibrated wire, and in‑process checks. We verify aperture, wire dia, open area per batch and can frame/cut panels to your drawings. 35+ years of supply experience across India. SS 316 options for corrosive zones and hygiene‑critical services.
Frequently Asked Question
Trusted in more than 100 countries and 4 million customers.
Zig-Zag crimp (Z) provides a more rigid mesh with reduced wire slippage, making it the preferred choice for heavy-duty screening. Plain crimp (P) is used for lighter applications or where a smoother surface is required.
Yes. We manufacture screens with clamps (WSC) customised to fit any vibrating screen machine. Provide your machine make, model, and frame dimensions, and we will manufacture the screen to exact specifications.
Spring Steel, also called High Carbon Steel, is the most durable and cost-effective material for heavy-duty screening. It offers excellent abrasion resistance and spring-back properties. Use SPS for aggregate, mining, and quarrying. Use SS304/316 where corrosion resistance is required.
Lifespan depends on the material being screened, the screen material, and operating conditions. SPS screens in aggregate applications typically last 3-6 months. SS screens in chemical or food applications last longer due to lower abrasion.
We stock popular roll sizes (WSS) in SPS, SS304, and GI for immediate dispatch. Clamped screens (WSC) are made to order since every machine has different frame dimensions. Typical lead time is 3-5 working days.
Use our online pricing tool for standard crimped mesh roll prices. For clamped screens (WSC), WhatsApp us your machine details and screen dimensions for a quotation within 24 hours.
